New Black and White AR0144 Senor Global Shutter For Raspberry Pi USB Camera Module

Product Features

* High quality Aptina AR0144 Sensor for high quality image
* Shutter Type -Global shutter for fast computer vision
* High frame rate – deliver 1280X720MJPEG@ 60fps
* Black & white image
* M12 no distortion lens
* UVC compliance for use in OS Windows,Linux, Android



Description:

Global shutter camera advantages:
Improved image quality for fast moving objects
Total Noise Floor Reduction, SNR Improvement
High Dynamic Range
Ideal for battery powered applications

1.Sensor: With high quality AR0144 Sensor for high quality image, monochrome/color optional

2.Resolution: HD 1280*720 High Resolution 720P Global Shutter USB Camera;

3.High Speed: Mjpeg 60FPS@1280*720

4.Megapixel Lens: High Quality lenses with M12 mount

5.High Quality Image: Super Image reality, real color reproduction, without interpolation;

6.UVC Support: Free Driver , Plug and Play, easily used on different systems;

7.Support Systems: Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi…;

8.OTG Support: can be used on Android smartphone, recommended app “USB Camera”.

9.Wide Application: Well used for High Speed- sports photography, AI object recognition, Industrial inspection, Video applications, Industrial automation, robotics, or scientific imaging. Some can also be used for Augmented and virtual reality, gesture and eye tracking, depth and motion detection…. and so on

Specifications: ​

Model

SMK-USBGS720P02-L100

Sensor

Aptina AR0144

Lens Size

1/4 inch

Pixel Size

3.0µm

image area

3888µm x 2430 µm

Effective Pixels

1280(H)X720(V)  1MP

Compression format

MJPEG / YUV2 (YUYV)

Resolution & frame

1280X720MJPEG@ 60fps YUY2@5fps
800X600MJPEG@ 60fps YUY2@20fps
640X480 MJPEG@ 60fps YUY2@ 30fps

S/N Ratio

38dB

Dynamic Range

63.9dB

Sensitivity

3.1V/lux-sec@550nm

Mini illumination

0.2 Lux

Shutter Type

Global Shutter

Connecting Port type

USB2.0 High Speed

OTG protocol

USB2.0 OTG

Free Drive Protocol

USB Video Class(UVC)

AEC

Support

AEB

Support

AGC

Support

Adjustable parameters

Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,
Gain, White balance, Backlight Contrast, Exposure

Lens Parameter

Standard no distortion lens (2.1//2.8/ 3.6/6/8/12mm/ fisheye lens optional)

Power supply connector

USB BUS POWER  4P-2.0mm socket

Work Power Voltage

DC5V

Work Power Current

110mA~160mA

Working temperature

 -10~70℃

Storage temperature

 -20~75℃

Board size /Weight

38*38/32*32mm / About 30g

Cable

Standard 1m cables (2M,3M,5M optional )
